Operating Instructions Chapter 12
M4000 Adv., Adv. A/P, Area
8010797/PA53/27-06-05 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
91
Ordering information
M4000 Advanced
with M26 Hirschmann plug,
M12× 5 socket
24)
and
integrated alignment aid
Type code Type codeNumber
of
beams
Beam
separation
[mm]
Sender Receiver
500 M40S-025013AA0 M40E-025013RB0
2
600 M40S-026013AA0 M40E-026013RB0
400 M40S-034013AA0 M40E-034013RB0
3
450 M40S-034513AA0 M40E-034513RB0
4 300 M40S-043013AA0 M40E-043013RB0
M4000 Advanced
with M26 Hirschmann plug,
M12× 5 socket
24)
and
end cap with integrated LED
25)
Type code Type codeNumber
of
beams
Beam
separation
[mm]
Sender Receiver
500 M40S-025003AA0 M40E-025023RB0
2
600 M40S-026003AA0 M40E-026023RB0
400 M40S-034003AA0 M40E-034023RB0
3
450 M40S-034503AA0 M40E-034523RB0
4 300 M40S-043003AA0 M40E-043023RB0
M4000 Advanced
with M26 Hirschmann plug,
M12× 5 socket
24)
,
integrated alignment aid and
end cap with integrated LED
25)
Type code Type codeNumber
of
beams
Beam
separation
[mm]
Sender Receiver
500 M40S-025013AA0 M40E-025033RB0
2
600 M40S-026013AA0 M40E-026033RB0
400 M40S-034013AA0 M40E-034033RB0
3
450 M40S-034513AA0 M40E-034533RB0
4 300 M40S-043013AA0 M40E-043033RB0
12.1.3 Default delivery status
• The pre-setting for the device configuration is termed the default delivery status. You
can accept or change these pre-settings (see chapter 8 “Configuration” on page 64).
• The default delivery status is only applicable for the device types listed in
chapter 12.1.2 “Type code” on page 90ff.
24)
Receiver only: extension connection for UE403.
25)
Receiver only.
Advanced with M26 plug and
integrated alignment aid
Advanced with M26 plug and
end cap with integrated LED
Advanced with M26 plug,
integrated alignment aid and
end cap with integrated LED
Notes
