SICK M4000 Advanced

Chapter 11 Operating Instructions
M4000 Adv., Adv. A/P, Area
84 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/PA53/27-06-05
Technical specifications
11.3.3 M4000 Area 60/80
Fig. 50: Dimensional drawing
M4000 Area 60/80 receiver,
sender mirror image (mm)
71.2
S
L1
L2
14.4
55.5
27.5
25.5
Sliding nut
groove
for
side mounting
14
6
10.5
2.2
3.5
1
Cable socket M26 with crimp contacts
(for DIN 43  651)
Ca. 125
(connector range)
87
52
52
71.2
S
L1
L2
14.4
M4000
Area
60
M4000
Area
80
