Page #66 background imageLoading...
Page #66 background image
Chapter 10 Operating Instructions
M4000 Adv., Adv. A/P, Area
66 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/PA53/27-06-05
Fault diagnosis
10 Fault diagnosis
This chapter describes how to identify and remedy errors and malfunctions during the
operation of the M4000 multiple light beam safety device.
10.1 In the event of faults or errors
WARNING
Cease operation if the cause of the malfunction has not been clearly identified!
Stop the machine if you cannot clearly identify or allocate the error and if you cannot
safely remedy the malfunction.
Complete function test after rectification of fault!
After rectifying a fault, perform a complete function test as per section 7.3 “Test notes”.
The lock@out status
In case of certain faults or an erroneous configuration, the system can go into the lock@out
status. The 7@segment display on the multiple light beam safety device then indicates or
a defined error message (see Tab. 26).
First check whether the lock@ out status is still present after switching on and off the
M4000 (e.g. by disconnecting the system plug and re-connecting).
To place the device back in operation:
Rectify the cause of the fault as per Tab. 26.
Switch the power supply for the M4000 off and on again (e.g. by unplugging the system
plug and reinserting it).
The lock@ out status has the highest priority above all other indications on the 7@segment
display.
10.2 SICK support
If you cannot remedy an error with the help of the information provided in this chapter,
please contact your local SICK representative.
10.3 Error displays of the LEDs
This chapter explains the meaning of the error displays of the LEDs and how to respond.
You will find an description of the LEDs in chapter 3.4 “Controls and status indicators” on
page 18.
Note
