Ordering information
12 Ordering information
12.1 M4000 Advanced
12.1.1 Delivery
 Sender  Receiver
• sender unit
• 4 sliding nuts for side bracket
• receiver unit
• 4 sliding nuts for side bracket
• label “Important Information”
• operating instructions on CD@ROM
• CDS (Configuration & Diagnostic
Software) on CD@ROM
12.1.2 Type code
M4000 Advanced
with M26 Hirschmann plug and
M12× 5 socket
23)
Type code Type codeNumber
of
beams
Beam
separation
[mm]
 Sender  Receiver
500 M40S-025003AA0 M40E-025003RB0
2
600 M40S-026003AA0 M40E-026003RB0
220 M40S-032203AA0 M40E-032203RB0
400 M40S-034003AA0 M40E-034003RB0
3
450 M40S-034503AA0 M40E-034503RB0
220 M40S-042203AA0 M40E-042203RB0
4
300 M40S-043003AA0 M40E-043003RB0
5 M40S-052203AA0 M40E-052203RB0
6 M40S-062203AA0 M40E-062203RB0
7 M40S-072203AA0 M40E-072203RB0
8
220
M40S-082203AA0 M40E-082203RB0
23)
Receiver only: extension connection for UE403.
Tab.
35
:
Delivery
M4000 Advanced
Tab.
36
:
Type codes
M4000 Advanced with
M26 plug
