SICK M4000 Advanced Manual

Operating Instructions Chapter 12
M4000 Adv., Adv. A/P, Area
8010797/PA53/27-06-05 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
97
Ordering information
12.5 Deflector mirrors and mirror columns
Description Part number
Deflector mirror PNS75-008, including mounting kit 1026647
Deflector mirror PSK45, including mounting kit, not suitable for
column mounting
5306053
Mirror column, fully assembled with mirrors
Suitable for M40#-0250#####, 2@beam, 500 mm beam separation
1027199
Mirror column, fully assembled with mirrors
Suitable for M40#-0260#####, 2@beam, 600 mm beam separation
1027290
Mirror column, fully assembled with mirrors
Suitable for M40#-0340#####, 3@beam, 400 mm beam separation
1027289
Mirror column, fully assembled with mirrors
Suitable for M40#-0345#####, 3@beam, 450 mm beam separation
1027288
Mirror column, fully assembled with mirrors
Suitable for M40#-0430#####, 4@beam, 300 mm beam separation
1027291
Mirror column, fully assembled with mirrors (45°)
Suitable for M40Z-02500#### and M40Z-02501####,
2@beam, 500 mm beam separation
1027265
Adjusting plate
Suitable for mirror and device columns
4031053
Mirror columns affect the scanning range of the system. On this subject see section 4.4
“Scanning range” on page 24ff.
Tab.
50
:
Part numbers
deflector mirrors and mirror
columns
Note
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
