Ordering information
Description Part number
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-0822#####
2033234
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-60#######
2033235
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-61#######
2033236
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-62#######
2033237
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-63#######
2033238
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-64#######
2033239
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-65#######
2033240
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-66#######
2033241
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-67#######
2033242
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-68#######
2033243
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-69#######
2033244
Additional front screen for M4000, including sliding nuts and fixing
screws, 2 pieces, suitable for:
M40#-70#######
2033245
• The additional front screens are bolted directly to the mounting groove on the M4000
using the sliding nuts and fixing screws.
• Each additional front screen fits both on the sender and on the receiver.
• An additional front screen reduces the scanning range of the system by 8%. If sender
and receiver each use an additional front screen, the scanning range will be reduced
by 16%.
Notes
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
