SICK M4000 Advanced Manual

Chapter 11 Operating Instructions
M4000 Adv., Adv. A/P, Area
78 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/PA53/27-06-05
Technical specifications
11.2 Table of weights
11.2.1 M4000 Advanced and M4000 Advanced A/P
Number of beams
Beam separation
[mm]
Type code Weight [g]
M40Z-0250#####
22)
1860
500
M40#-0250##### 1925
2
600 M40#-0260##### 2200
220 M40#-0322##### 1760
400 M40#-0340##### 2750
3
450 M40#-0345##### 3025
220 M40#-0422##### 2370
M40Z-0430#####
22)
3040
4
300
M40#-0430##### 3030
5 M40#-0522##### 2975
6 M40#-0622##### 3580
7 M40#-0722##### 4185
8
220
M40#-0822##### 4795
11.2.2 M4000 Passive
For number
of beams
Deflector unit Part number Type code Weight [g]
Mirror
deflection
1027906 PSD01-1501 1500
2
Fibre-optic
deflection
1027907 PSD01-2501 1760
4 Fibre-optic
deflection
1027908 PSD02-2301 2920
22)
M4000 Advanced A/P
Tab.
28
:
Table of weights
M4000 Advanced and
M4000 Advanced A/P
Tab.
29
:
Table of weights
M4000 Passive
