SICK M4000 Advanced Manual

Operating Instructions Chapter 11
M4000 Adv., Adv. A/P, Area
8010797/PA53/27-06-05 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
77
Technical specifications
Minimum Typical Maximum
Operating data
Connection Hirschmann plug M26× 11 + FE
Cable length
21)
50 m
Wire cross-section 0.75 mm
2
Ambient operating temperature 0 °C +55 °C
Air humidity
(non-dewing)
15%95%
Storage temperature –25 °C +70 °C
Housing cross-section 52 mm × 55.5 mm
Vibration resistance 5 g, 10-55 Hz acc. to IEC 60068@2@6
Shock resistance 10 g, 16 ms acc. to IEC 60068@2@29
Environmental data, materials
Housing Aluminium alloy ALMGSI 0.5 (powder coated)
Front screen Polycarbonate, scratch-resistant coating
End caps Polyamide 6.6 CF30
Packaging Corrugated cardboard with polyethylene inlays
Circuit boards Glass-fibre reinforced epoxy resin with flame
retarding agent TBBPA
M4000 Passive
Housing cross-section 52 mm × 55.5 mm
Weight, type-dependent See section 11.2 “Table of weights” on page 78ff.
21)
Depending on load, power supply and wire cross-section. The technical specifications must be observed.
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
