SICK M4000 Advanced

Chapter 11 Operating Instructions
M4000 Adv., Adv. A/P, Area
76 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/PA53/27-06-05
Technical specifications
Minimum Typical Maximum
Contactors
Permissible dropout time 300 ms
Permissible pick-up time 300 ms
Control switch input (reset button)
Input voltage
17)
HIGH (active) 11 V 24 V 30 V
Input current HIGH 6 mA 10 mA 20 mA
Input voltage
17)
LOW (inactive) –30 V 0 V 5 V
Input current LOW –2.5 mA 0 mA 0.5 mA
Operation time control switch
input
200 ms
Output Reset required PNP semiconductors, short-circuit protected
18)
(24 V lamp output) 4 W/0.2 A
Switching voltage HIGH (active) 15 V 24 V 28.8 V
Switching voltage LOW
(inactive)
High resistance
Application diagnostic output
(ADO)
PNP semiconductors, short-circuit protected
18)
Switching voltage HIGH (active) V
s
– 4.2 V 24 V V
s
Switching voltage LOW
(inactive)
High resistance
Switching current 0 mA 100 mA
Belt stop input/C1
Input voltage
17)
HIGH
(inactive
19)
, active
20)
)
11 V 24 V 30 V
Input current HIGH 6 mA 10 mA 20 mA
Input voltage
17)
LOW
(active
19)
, inactive
20)
)
–30 V 0 V 5 V
Input current LOW –2.5 mA 0 mA 0.5 mA
Operation time input 100 ms
Wavelength
M4000 Advanced A/P (sender
unit)
850 nm
Alignment laser (optional) Laser class 2. Complies with IEC 60825@1:2001
and 21 CFR 1040.10 and 1040.11 with the
exception of the deviations as per Laser Notice
No. 50, July 2001
Optical power output 1 mW
Wavelength 630 nm–680 nm (visible red light)
Weight, type-dependent See section 11.2 “Table of weights” on page 78ff.
18)
Applies to the voltage range between –30 V and +30 V.
19)
Belt stop.
20)
C1.
