SICK M4000 Advanced Manual

Chapter 12 Operating Instructions
M4000 Adv., Adv. A/P, Area
92 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8010797/PA53/27-06-05
Ordering information
ConfigurationFunction
 Sender  Receiver
Beam coding Non-coded Non-coded
Sender test Deactivated –
Restart interlock – Internal
External device
monitoring (EDM)
– Activated
Scanning range – 0.5-20 m
Application
diagnostic output
(ADO)
– Contamination
12.2 M4000 Advanced A/P
12.2.1 Delivery
  M4000 Advanced A/P M4000 Passive
• sender/receiver unit
• 4 sliding nuts for side bracket
• label “Important Information”
• operating instructions on CD@ROM
• CDS (Configuration & Diagnostic
Software) on CD@ROM
• deflector unit
• 4 sliding nuts for side bracket
12.2.2 Type code
M4000 Advanced A/P
with M26 Hirschmann plug and
M12× 5 socket
26)
Type code Part
number
Type codeNumber
of
beams
Beam
separation
[mm]
 
M4000 Advanced A/P
M4000 Passive
M40Z-025003RB0 1027906 PSD01-1501
27)
2 500
M40Z-025003TB0 1027907 PSD01-2501
28
)
4 300 M40Z-043003TB0 1027908 PSD02-2301
28)
26)
Receiver only: extension connection for UE403.
27)
With mirror deflection (max. effective scanning range 7.5 m).
28)
With fibre-optic deflection (max. effective scanning range 4.5 m).
Tab.
40
:
Default delivery
status M4000 Advanced
Tab.
41
:
Delivery
M4000 Advanced A/P
Tab.
42
:
Type codes
M4000 Advanced A/P with
M26 plug
AUDIN - 7 bis rue de Tinqueux - 51100 Reims - France - Tel : 03.26.04.20.21 - Fax : 03.26.04.28.20 - Web : http: www.audin.fr - Email : info@audin.fr

SICK M4000 Advanced Specifications

General

Type	Multiple light beam safety device
Enclosure rating	IP65
Supply voltage	24 V DC
Safety integrity level	SIL3
Performance level	PL e
Protection Rating	IP65
Operating Voltage	24 V DC
Number of beams	2 to 4 beams
Resolution	70 mm
Ambient operating temperature	-25 °C ... +55 °C
Angular Resolution	Not applicable
Operating Temperature	-25 °C ... +55 °C
