Chapter 5
MSC800
48 Operating instructions | SICK 8011540/14B8/2019-06-06
Subject to change without notice
Electrical installation
Connections for supply voltage OUT 1 on the MSC800-2300 for CLV490, VMS4xx/5xx,
and logic unit of the MSC800
Terminal Signal Function Protected by fuse
11+ DC +24 V Supply voltage OUT F1 (4 A, slow-acting)
12+
DC +24 V
Supply voltage OUT
F2 (4 A, slow-acting)
13+
DC +24 V
Supply voltage OUT
F3 (4 A, slow-acting)
14+ DC +24 V Supply voltage OUT F4 (4 A, slow-acting)
15+ DC +24 V Supply voltage OUT F5 (4 A, slow-acting)
16+
DC +24 V
Supply voltage OUT
F6 (2 A, slow-acting)
21–/22–/23–/
24–/25–/26–
GND Ground
Tab. 17 MSC800-2300: assignment of the 12-pin terminal block for
supply voltage OUT on CLV490, VMS4xx/5xx, and logic unit of the MSC800
