CLINITEK Status+ Analyzer Operator’s Guide 111
System Configuration
4. Select the connectivity options.
5. Select Next.
The Connectivity 2 of 2 screen displays.
6. Select Serial Connection.
7. Select Edit serial settings, and select the following options:
a. For Baud rate, select 9600, 19200, 57600, or 115200.
b. Select Next.
c. For Parity, select None, Odd, or Even.
d. Select Next.
e. For Stop Bits, select 1 or 2.
8. Select Done 4 times to return to the Select Ready screen.
Connectivity Option Description
Screen 1 of 2
Connectivity Platform • Enabled allows
communication between the
analyzer and the connector.
• Disabled (default) prevents
communication between the
analyzer and the connector.
Allow results to be sent
to PC
• Enabled (default) allows the
analyzer to send the test
results to a PC.
• Disabled prevents the
analyzer from sending the
test results to a PC.
Note If you do not use a
CLINITEK Status connector,
Siemens recommends that you
select Disabled.

Siemens CLINITEK Status+ Specifications

General

Display	LCD
Sample Type	Urine
Measurement Method	Reflectance photometry
Type	Urinalysis Analyzer
Test Types	Urine Chemistry
Connectivity	RS232 port
Weight	5.0 kg
Power Supply	100-240 V AC, 50-60 Hz
Data Storage	Up to 200 patient results
Test Parameters	Leukocytes, Nitrite, Urobilinogen, Protein, pH, Blood, Specific Gravity, Ketone, Bilirubin, Glucose
Test Strips	Multistix and other compatible strips
