Figure 1-1: ClinitekStatus+ Analyzer Components
Assembling the ClinitekStatus+ Analyzer
After you unpack the analyzer components, you can assemble and
connect them.
To assemble the ClinitekStatus+ Analyzer components, perform the
following steps:
1 ClinitekStatus+ Analyzer
2 Power supply adaptor and AC power cord (Figure shows US
version)
3 Test table with calibration bar
4 Test table insert
5Paper roll
