24 CLINITEK Status+ Analyzer Operator’s Guide
Introduction
The CLINITEK Status+ analyzer provides several screen elements:
option, area, button, arrow, and double arrows.
Screen
Element
Example Description
Option Round option buttons
display on screens where
you select an option. The
option button with a filled
circle is the current
selection. For example,
Sound on, Sound off, and
Key clicks only are
instrument setup options.
To change your selection,
select an option button with
an unfilled circle. The newly
selected circle (round
option button) is
highlighted. In the example,
the Sound on option is
selected.
Selection
Area
Selection areas enclosed in
boxes on the screen
indicate functions that you
can select. Select a boxed
area to activate that
function. For example, Strip
Test.
An area varies in size. For
example, the boxes on the
Select Ready screen are
large areas.
