26 CLINITEK Status+ Analyzer Operator’s Guide
Introduction
Arrow Select the up and down
arrows on the right side of
the screen to scroll through
the items in a list and
highlight an item on the left
side of the screen. Select
the Select button to
confirm your selection and
move to the next screen.
When an arrow is
highlighted, you can use it
to scroll. When an arrow is
dimmed, you are viewing
the first item or last item in
the list, and cannot scroll
beyond that page.
Note When an item in a
list displays a highlighted
bar, you can select that
item.
Double
Arrows
When double arrows display
on the screen, you select
these arrows to move to the
top or bottom of the page.
When a double arrow is
highlighted, you can use it
to scroll. When a double
arrow is dimmed, you are
viewing the first page or last
page of the list, and cannot
move beyond that page.
Screen
Element
Example Description

Siemens CLINITEK Status+ Specifications

General

Display	LCD
Sample Type	Urine
Measurement Method	Reflectance photometry
Type	Urinalysis Analyzer
Test Types	Urine Chemistry
Connectivity	RS232 port
Weight	5.0 kg
Power Supply	100-240 V AC, 50-60 Hz
Data Storage	Up to 200 patient results
Test Parameters	Leukocytes, Nitrite, Urobilinogen, Protein, pH, Blood, Specific Gravity, Ketone, Bilirubin, Glucose
Test Strips	Multistix and other compatible strips
