Siemens LME7 Series Basic Documentation

111/245
Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 16 PME73.820... 29.11.2011
16.3 Connection diagram for LME73.000... with
actuator SQM4... (example 1)

Note:
The connection diagram shown is merely an example which must be verified in the individual case
depending on the application!
PME73.820... 1-/2-stage modulating
Without pilot ignition
With/without valve proving
X3X2X1 123
V
IV
III
5
M
III
V
I
213412345
6
I
VI
V
IV
III
II
7105d15e/1009
X2-09
SA-Z
SA-KL
SA-NL
SA-R
PE
Input to cam V2
Output to cam V2
Figure 52: Connection diagram for LME73.000... with actuator SQM4... (example 1)
