Siemens LME7 Series Basic Documentation

158/245
Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 19 PME73.840... 29.11.2011
19.7 Parameter list PME73.840... (AZL2...)
Value range Parameter
number
Parameter Edit
Min. Max.
Resolution Factory setting Password level
reading from level
Password level
writing from level
000 Internal parameter
41 Heating engineer's password (4 characters) Edit xxxx xxxx --- --- --- OEM
42 OEM's password (5 characters) Edit xxxxx xxxxx --- --- --- OEM
60 Backup/restore Edit Restore Backup --- --- --- SO
100 General
102 Identification date Read only --- --- --- --- Info ---
103 Identification number Read only 0 9999 1 0 Info ---
113 Burner identification Edit x xxxxxxxx 1 burnErId Info SO
140 Mode display of display and operating unit AZL2...
1 = standard (program phase)
2 = flame 1 (QRA.../ION)
3 = flame 2 (QRB.../QRC...)  not used
4 = active power (power value)
Edit 1 4 1 1 SO SO
164 Number of startups resettable Resettable 0 999999 1 0 Info Info
166 Total number of startups Read only 0 999999 1 0 Info ---
170.00 Switching cycles actuator relay K12 Read only 0 999999 1 0 Info ---
170.01 Switching cycles actuator relay K11 Read only 0 999999 1 0 Info ---
170.02 Switching cycles actuator relay contact 2 Read only 0 999999 1 0 Info ---
170.03 Switching cycles actuator relay contact 1 Read only 0 999999 1 0 Info ---
171 Max. switching cycles actuator relay Read only 0 999999 1 0 Info ---
