Building Technologies Division Basic Documentation LME7... CC1P7105de
Infrastructure & Cities Sector 10 PME71.401... 29.11.2011
10.5 Parameter list PME71.401... (AZL2...)
Value range Parameter
number
Parameter Edit
Min. Max.
Resolution Factory setting Password level
reading from level
Password level
writing from level
000 Internal parameter
41 Heating engineer's password (4 characters) Edit xxxx xxxx --- --- --- OEM
42 OEM's password (5 characters) Edit xxxxx xxxxx --- --- --- OEM
60 Backup/restore Edit --- --- --- --- --- SO
100 General
102 Identification date Read only --- --- --- --- Info ---
103 Identification number Read only 0 9999 1 0 Info ---
113 Burner identification Edit x xxxxxxxx 1 --- Info SO
140 Mode display of display and operating unit AZL2...
1 = standard (program phase)
2 = flame 1 (QRA.../ION)
3 = flame 2 (QRB.../QRC...)  not used
4 = active power (power value)
Edit 1 4 1 1 SO SO
164 Number of startups resettable Resettable 0 999999 1 0 Info Info
166 Total number of startups Read only 0 999999 1 0 Info ---
170.00 Switching cycles actuator relay K12 Read only 0 999999 1 0 Info ---
170.01 Switching cycles actuator relay K11 Read only 0 999999 1 0 Info ---
170.02 Switching cycles actuator relay contact 2 Read only 0 999999 1 0 Info ---
170.03 Switching cycles actuator relay contact 1 Read only 0 999999 1 0 Info ---
171 Max. switching cycles actuator relay Read only 0 999999 1 0 Info ---
200 Burner control
224 Specified time air pressure switch Edit 0 s 13.818 s 0.294 s 13.818 s SO
OEM
225 Prepurge time -2,1 seconds Edit 0 s 1237 s 4.851 s 29.106 s SO
OEM
226 Preignition time Edit 1.029 s 37.485 s 0.147 s 2.058 s SO
OEM
230 Interval: End of safety time – load controller release Edit 3.234 s 74.97 s 0.294 s 8.232 s SO
OEM
234 Postpurge time Edit 0 s 1237 s 4.851 s 0 SO
OEM
240 Repetition in the event of loss of flame during
operation
0 = none
1 = none
2 = 1 x repetition
Edit 0 2 1 0 SO
OEM
257 Postignition time -0.3 seconds Edit 0 s 13.23 s 0.147 s 2.205 s SO
OEM
