3.2 Program module
Example:
Typenbezeichnung
PME71.401A1 PME71.402A1 PME71.901A1 PME73.810A1 PME73.820A1 PME73.830A1 PME73.831A1 PME73.840A1
Mains voltage AC 120 V
● ● ● ● ● ● ● ●
For use with LME71.000A...
● ● ●
--- --- --- --- ---
For use with LME72.000A... --- --- --- --- --- --- --- ---
For use with LME73.000A... --- --- ---
● ● ● ● ●
Gas program forced draft burner
● ● ● ● ● ● ● ●
Gas program atmospheric burner --- --- --- --- --- --- --- ---
1-stage/2-stage or 1-stage modulating
● ● ● ● ● ● ● ●
Pilot burner simultaneously/alternately ---
●
--- --- ---
● ● ●
Modulating via actuator (pneumatic or mechanic gas-air ratio
control)
--- --- ---
● ● ● ● ●
Modulating via PWM fan (pneumatic or mechanic gas-air ratio
control)
--- ---
●
--- --- --- --- ---
Fan speed control/control via analog signal/3-position step
signal
--- ---
●
--- --- --- --- ---
Actuator control via analog signal/3-position step signal for
actuator with potentiometer
--- --- ---
●
---
● ●
---
3-position signal for actuator without potentiometer --- --- --- ---
●
---
● ●
Control sequence programmable time
● ● ● ● ● ● ● ●
POC
● ● ● ● ● ● --- ●
Valve proving --- ---
● ● ● ● ● ●
Input valve proving ON/Off --- ---
--- --- --- --- ● ---
