Siemens LME7 Series - Gas Pilot Ignition 1 (Gp1), 1-Stage, with Valve Proving, Alternate Burning Ignition Burner; Gas Direct Ignition 1 (G), 1-Stage, with Valve Proving

136/245
Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 18 PME73.831… 29.11.2011
18.2.3 Gas pilot ignition 1 (Gp1), 1-stage, with valve proving,
alternate burning ignition burner
SV
V1
Program Gp1 Gas pilot 1, 1-stage
PV
X7-01 X7-04
V2
X7-02
LME73.000...
Fuel valve control
X7-01: PV
X7-04: V1
X7-02: V2
t1 t3 TSA t4 t9 Operationt5
Fif. 69: Connection diagram fuel application gas pilot ignition 1 (Gp1), 1-stage, with valve proving
18.2.4 Gas direct ignition 1 (G), 1-stage, with valve proving
SV
V1
Program G Gas direct 1, 1-stage
V2
X7-02
LME73.000...
X7-04X7-01
Fuel valve control
X7-01:
X7-04: V1
X7-02: V2
t1 t3 TSA t4 t9 Operationt5
Fig 70: Connection diagram fuel application gas direct ignition 1 (G), 1-stage, with valve proving

Note:
When valve proving is activated (e.g. on shutdown), the load on the valve’s
terminals (according to chapter Technical data/Terminal rating Outputs) is
restricted.
Fuel valve 1 X7-04 pin 4/fuel valve 2 X7-02 pin 3/auxiliary output AUX
 Rated voltage AC 120 V AC 230 V
50/60 Hz 50/60 Hz
 Rated current 1 A 1 A
 Power factor cos >0.4 cos >0.4
If the terminal load (according to chapter Technical data/Terminal rating
Outputs) is not reduced (max. rated current 2 A, cos >0.4), the design
lifetime will be reached after about 100,000 burner startup cycles!
