Building Technologies Division Basic Documentation LME7... CC1P7105en

Infrastructure & Cities Sector 25 Operation via internal LED 29.11.2011

25.2 Normal display

Normal display is the standard display in normal operation.

25.2.1 Display in standby mode

LCD Bild 02/0908

Unit is in standby mode.

25.2.2 Display during startup/shutdown

25.2.2.1. Display of program phases

LCD Bild 03/0908

The unit is in Phase 21. The individual program phases are

displayed in accordance with the program sequence.

For color display of signal lamp, see List of phase display.
