Building Technologies Division Basic Documentation LME7... CC1P7105en

Infrastructure & Cities Sector 18 PME73.831… 29.11.2011

18.2 Connection diagrams for fuel applications

(examples)

18.2.1 Gas direct ignition (G), 1-stage, without valve proving

Program

Gas direct 1-stage

X2-02

LT (ON/OFF)

LME73.000...

X7-04

LME73.000...

X7-01

Fuel valve control

X7-01:

X7-04: V1

X7-02

t1 t3 TSA t4 t9 Operationt5

Fig. 67: Connection diagram fuel application gas direct ignition (G), 1-stage, without valve proving

18.2.2 Gas pilot ignition 2 (Gp2), 1-stage, without valve proving,

simultaneously ignition burner

Program

Gp2

Gas pilot 2, 1-stage

X7-02 X7-04

LME73.000...

Fuel valve control

X7-01:

X7-04: PV

X7-02: V1

t1 t3 TSA t4 t9 Operationt5

X2-02

LT (ON/OFF)

LME73.000...

Fig. 68: Connection diagram fuel application gas pilot ignition 2 (Gp2), 1-stage, without valve proving
