Siemens LME7 Series Basic Documentation

38/245
Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 6 Function 29.11.2011
6 Function
6.1 Preconditions for burner startup
 Burner control must be reset
 All contacts in the line are closed, there is a request for heat
 No undervoltage
 Air pressure switch or POC must be in its no-load position, or Dbr1 is connected to
X2-02 (depending on program sequence)
 Flame detector is darkened and there is no extraneous light
 All contacts in the safety loop are closed
6.2 Undervoltage
 Safety shutdown from the operating position takes place should mains voltage drop
below about AC 75 V (UN = AC 120 V)
 Restart is initiated when mains voltage exceeds about AC 100 V (UN = AC 120 V)
 Safety shutdown from the operating position takes place should mains voltage drop
below about AC 165 V (UN = AC 230 V)
 Restart is initiated when mains voltage exceeds about AC 195 V (UN = AC 230 V)
6.3 Controlled intermittent operation
Depending on parameter 239, after no more than 24 hours of continuous operation, the
burner control initiates automatic controlled shutdown followed by a restart, against
parameter 239.
