4.7 Signal cable AGV50...
4.7.1 AZL2...  BCI
Signal cable
Color white
Unshielded
Conductor 4 x 0.141 mm²
With jack RJ11
Cable length
- AGV50.100 1 m
Supplier (alternative) Recommendation:
Hütter
http://www.hkt-
netzwerktechnik.at/index.htm
Location Under the burner hood (arrangements for
SKII EN60730-1 additionally required)
4.8 Dummy plug for RJ11
Dummy plug
For 6 pin modular plug (RJ11)
Supplier Recommendation:
Molex
Order no.: 085 999 3256
4.9 Environmental conditions
Storage
DIN EN 60721-3-1
Climatic conditions Class 1K3
Mechanical conditions Class 1M2
Temperature range -40...+70 °C
Humidity <95% r.h.
Transport
DIN EN 60721-3-2
Climatic conditions Class 2K3
Mechanical conditions Class 2M2
Temperature range -40...+70 °C
Humidity <95% r.h.
Operation
DIN EN 60721-3-3
Climatic conditions Class 3K3
Mechanical conditions Class 3M2
Temperature range -40...+60 °C
Humidity <95% r.h.
Warning!
Condensation, formation of ice and ingress of water are not permitted!
If not observed, there is a risk of impairment of safety functions and of
electric shock hazard.
