Siemens LME7 Series Basic Documentation

225/245
Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 27 PWM settings 29.11.2011
27.4 Initial PWM parameter settings
27.4.1 Initial settings of PWM basic parameters

Note:
The initial settings of the PWM basic parameter are made exclusively on the OEM
level.
Prerequisites
 Operating unit AZL2... for setting the parameters is connected
 Unit is wired up in accordance with the proposed application
 Mains voltage is available
 Safety loop is closed
 There is no heat request, unit is in standby (OFF)
 Fan parameters, such as maximum speed and Hall signal (number of pulses per
revolution) are known
 With unprogrammed program module (initial settings), AZL2... displays OFF UPr
 With unprogrammed program module (initial settings), the onboard operating panel
of the LME7... displays UPr
Operating steps
 Select programming mode for OEM
 Press
A
and
F
simultaneously for <5 seconds. Display shows CodE
 Enter the OEM’s password via
, and
/
reset
. Also see chapter Entering the
password
 Display shows PArA and then 400: SEt. Confirm by pressing
/
reset
 Unit jumps to setting parameter P0 (ignition load position) 516.00 (516 blinking).
Keep
/
reset
depressed for >1 second. Subindex 00 is blinking
 Keep
/
reset
depressed for >1 second. Display changes to -. Also see chapter
Setting parameters with index, with or without direct display
 By pressing
or the speed can be changed in step sizes of 10 rpm. Set the
required minimum limit speed for the ignition load position at which the burner can
still be safely ignited
 Press
/
reset
to transfer the setting value to the onboard memory
 By pressing
ESC
(press and simultaneously) you leave the entry level
and return to the selection level for the subindex
 Subindex 00 blinks. Press
to select the next subindex. Subindex 01 blinks
 Press
/
reset
for >1 second. Display changes to -
 By pressing
or the speed can be changed in step sizes of 10 rpm. Set the
required maximum limit speed for the ignition load position at which the burner may
still be safely ignited
 Press
/
reset
to transfer the setting value to the onboard memory
 By pressing
ESC
twice (press and simultaneously) you leave the
entry level and return to the selection level for the parameter number
