Building Technologies Division Basic Documentation LME7... CC1P7105en

Infrastructure & Cities Sector 3 Type summary 29.11.2011

3.10 Test case and accessories

KF8895.1A9

Test case for LME...

 For simulations of burner functions as startups,

sequence of operations in connection with the specified

burner controls

 For check and test purposes of burner controls

 For operation in laboratories by expert qualified

personnel

See User Manual CC1U7993

AGV8895.01

Connection cable set for LME7…

 For test case KF8895.1A9

 Consisting of:

AGV8895.01X1

Connection cable for mains potential

 For test case KF8895.1A9

AGV8895.01X3

Connection cable for extra-low voltage, PELV

 For test case KF8895.1A9
