Siemens LME7 Series - Identification of Burner

178/245
Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 23 Operation via AZL2… 29.11.2011
23.6.2.3. Identification of burner
P
Vh
mi n
s%
Bild 32/0707
On the left, parameter 113: (108 with sample units)
is displayed blinking. On the right, ._._ appears.
Example: 113: ._._
/
reset
1…3 s
P
Vh
mi n
s%
Bild 33/0707
Press
/
reset
for 1…3 seconds to display the
burner’s identification.
Factory setting: - - - - - - - -
Example: 3
P
Vh
mi n
s%
Bild 162/1107
burnEr Id can only be changed with the ACS410
PC software diagnostic tool.
/
reset
or
ESC
P
Vh
mi n
s%
Bild 32/0707
Press
/
reset
or
ESC
to return to the display of
parameters.
To the next parameter
Back to the previous
parameter
