27.3 PWM safety parameters



Note:

Also see chapter Initial PWM parameter settings!

Parameter Meaning

559 PWM mode control

Determines the behavior of PWM control, delivering a PWM signal proportional to the preset output

(analog/3-position step input).

Control: Controls the PWM speed proportional to the output preset via the analog or 3-position step

input.

Safety mode: Control for defining the PWM safety parameters.

675.00 Minimum PWM with prepurging, SEC

Minimum PWM signal in percent for prepurging

675.01 Maximum PWM with ignition load, SEC

Maximum PWM signal in percent for ignition load

920 (Current) PWM signal fan

PWM signal in percent.

Readable on the service level with AZL2... (press Info button for >3 seconds).
