Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 19 PME73.840... 29.11.2011
Value range Parameter
number
Parameter Edit
Min. Max.
Resolution Factory setting Password level
reading from level
Password level
writing from level
200 Burner control
224 Specified time air pressure switch Edit 0 s 13.818 s 0.294 s 13.818 s SO OEM
225 Prepurge time -2,1 seconds Edit 0 s 1237 s 4.851 s 29.106 s SO OEM
226 Preignition time Edit 1.029 s 37.485 s 0.147 s 6.174 s SO OEM
230 Interval: End of safety time - fuel valve 1 ON Edit 3.234 s 74.97 s 0.294 s 9.408 s SO OEM
231 Interval: Fuel valve 1 ON - pilot valve OFF Edit 0 s 74.97 s 0.294 s 2.646 s SO OEM
232 Interval: Pilot valve OFF - load controller release Edit 2.058 s 74.97 s 0.294 s 8.820 s SO OEM
234 Postpurge time Edit 0 s 1237 s 4.851 s 19.404 s SO OEM
240 Repetition in the event of loss of flame during operation
0 = none
1 = none
2 = 1 x Repetition
Edit 0 2 1 0 SO OEM
241.00 Valve proving
0 = OFF
1 = ON
Edit 0 1 1 1 SO OEM
241.01 Valve proving
0 = during prepurge time
1 = during postpurge time
Edit 0 1 1 1 SO OEM
241.02 Valve proving
0 = according to P241.01
1 = during prepurge time and postpurge time
Edit 0 1 1 0 SO OEM
242 Valve proving test space filling Edit 0 s 2.648 s 0.147 s 2.648 s SO OEM
243 Valve proving time test atmospheric pressure Edit 1.029 s 37.485 s 0.147 s 10.290 s SO OEM
244 Valve proving test space evacuating Edit 0 s 2.648 s 0.147 s 2.648 s SO OEM
245 Valve proving time test gas pressure Edit 1.029 s 37.485 s 0.147 s 10.290 s SO OEM
247 Continuous pilot (during operation)
0 = OFF
1 = ON
Edit 0 1 1 0 SO OEM
257 Postignition time -0.3 seconds Edit 0 s 13.23 s 0.147 s 2.205 s SO OEM
259 Opening time of actuator (timeout) Edit 0 s 1237 s 4.851 s 300.762 s SO OEM
260 Closing time of actuator (timeout) Edit 0 s 1237 s 4.851 s 300.762 s SO OEM
515.00
Actuator position during prepurge time and postpurge time
0: Purging in low-fire
1: Purging in high-fire
Edit 0 1 1 1 SO OEM
515.01
Application with/without actuator
0: Without actuator
1: With actuator
Edit 0 1 1 1 SO OEM
