119/245
Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 17 PME73.830... 29.11.2011
Phase
number
Function
LOC Lockout shutdown phase
OFF Standby, waiting for heat request
oP:xx Part 1: Request load controller OPEN
Part 2: Modulation of actuator toward high-fire
Part 3: High-fire reached
Part 4: Request load controller CLOSE
Part 5: Modulation of actuator toward low-fire
Part 6: Low-fire reached
oP:P1 Interval: Pilot valve OFF and release of load controller
10 Actuator travels to the CLOSED position, home run
21 Safety valve ON, air pressure switch in no-load position
Check if POC is closed, actuator travels to the CLOSED position
22 Part 1: Fan motor ON
Part 2: Specified time air pressure switch
Message (timeout), stabelization of air pressure switch
24 Opening time of actuator (timeout)
30 Part 1: Prepurge time without flame simulation test
Valve proving when…
parameter 241 = 1 after power ON lockout, or
parameter 234 (postpurge time) = 0 seconds
Part 2: Prepurge time with flame simulation test (2.1 seconds)
36 Closing time of actuator (timeout)
38 Preignition time
40 Postignition time, parameter 257 + 0.3 seconds
42 Flame detection
44 Interval: End of ignition safety time and fuel valve 1 ON
50 Part 1: Interval: Fuel valve 1 ON and pilot valve OFF
Part 2: Response time
72 Opening time of actuator (timeout)
74 Part 1: Operation is ended, check if postpurging is programmed
Part 2: Postpurge time
Valve proving when…
parameter 241 = 1, and
parameter 234 (postpurge time) >0 seconds
80 Test space is evacuated
81 Atmospheric pressure test
82 Test space is filled
83 Gas pressure test
90 Pressure switch-min open → safety shutdown
*) During the actuator’s running phases, the actuator’s feedback signal must
first be OFF, then ON
*1 Valve proving, if P241.00 = 1 after mains ON, lockout or P234
(postpurge time) or P241.01 = 0 second
*2 Valve proving, if P241.00 = 1 and P234 (postpurge time) >0 second
Key to phases
