Building Technologies Division Basic Documentation LME7... CC1P7105en

Infrastructure & Cities Sector 25 Operation via internal LED 29.11.2011



Note:

 When the program phase (e.g. P10 - shutdown) changes during manual adjustment, the

display blinks

 Manual adjustment mode remains active until Escape switches the basic unit back to

normal operation or until the basic unit is reset via mains ON/OFF. This means that in the

case of a new heat request and after startup, the actuator or the PWM fan is driven to the

position or speed of the manually preset value
