Siemens PROFINET SIRIUS 3RW5 - Data sets

Process data Process image 3RW
50 /
52
1)
55
2)
55-F
3)
DQ 1.2 Parameter set bit 0
8)
- x x
DQ 1.3 Parameter set bit 1
8)
- x x
DQ 1.7 Disable Quick-stop - x x
DQ 2.0 Output 3
6)
- x -
DQ 2.3 Activate pump cleaning - x x
DQ 3.0 Manual operation local - input controlled x x x
DQ 3.1 Use alternative stopping mode - x x
DQ 3.2 Motor standstill - x -
1)
Supported by SIRIUS 3RW50 and 3RW52 soft starters
2)
Supported by SIRIUS 3RW55 soft starter
3)
Supported by SIRIUS 3RW55 Failsafe soft starter
4)
In order to perform the reset reliably, the control command "Reset" must be present for at least 20 ms.
5)
Control data is relevant for EX applications
6)
You can assign the control data "Output 1", "Output 2" and "Output 3" to the digital outputs 1, 2 and 4 of the 3RW55 soft starter
in any order via the digital output actions. You will 󹪝nd additional information in the Equipment Manual of the 3RW5 soft
starter.
7)
You can assign the control data "Output 1" and "Output 2" to the digital outputs 1 and 2 of the 3RW55 Failsafe soft starter in
any order via the digital output actions. You will 󹪝nd additional information in the Equipment Manual of the 3RW5 soft starter.
8)
Explanation in the following table
Additional information
The following table describes the assignment of the process images "Parameter set bit 0" and
"Parameter set bit 1":
Parameter set Parameter set bit 0 Parameter set bit 1
Process image error 1 1
Parameter set 1 (PS1) 0 0
Parameter set 2 (PS2) 1 0
Parameter set 3 (PS3) 0 1
A.4 Data sets
You can 󹪝nd an application example for reading and writing data sets with S7-1500 and HMI
connection on the Internet (https://support.industry.siemens.com/cs/ww/en/view/
109772107).
Data set Length 3RW
Number Description 50
1)
52
2)
55
3)
55‑F
4)
Commands
93 Commands (Page 160) 10 byte x x x x
Appendix
A.4 Data sets
SIRIUS 3RW5 PROFINET communication modules
Equipment Manual, 05/2021, A5E35631297002A/RS-AD/004 157
