Procedure
1. Install the le from the Hardware Support Package (HSP0238).
After installation, you will nd the 3RW5 soft starter in the HW Catalog of STEP 7 (TIA Portal).
Note
STEP 7 (TIA Portal) as of V16
3RW5 soft starters, 3RW5 communication modules and 3RW5 HMIs are already contained in
the HW catalog of STEP 7 (TIA Portal) as of V16. Check the 3RW5 topic page for updates and
ensure that your device and the current rmware are contained in the HW catalog.
2. Select the required 3RW5 soft starter from the HW catalog by means of the article number.
3. Add the 3RW5 PROFINET communication module from the HW catalog.
4. Connect the 3RW5 PROFINET communication module of the 3RW5 soft starter to the
PROFINET IO system or the controller.
Result
The 3RW5 soft starter is integrated into the PROFINET IO system as an IO device in STEP 7
(TIA Portal).
You can also integrate the 3RW5 soft starter via the GSDML le in STEP 7 (TIA Portal). (Page 63)
6.2.2.2 Integrating the 3RW5 Soft Starter into the PROFINET IO system with the GSDML le
Requirement
• GSDML le
The current PROFINET GSDML le can be found on the 3RW5 topic page (https://
support.industry.siemens.com/cs/ww/en/view/109747404).
• Conguration software of the controller that supports the schema version of the GSDML le,
e.g. STEP 7
– GSDML les for STEP 7 V5.x (https://support.industry.siemens.com/cs/ww/en/view/
109778885)
– GSD les for STEP 7 (TIA Portal) (https://support.industry.siemens.com/cs/ww/en/view/
109738401)
Procedure
1. Install the GSDML le.
After installation, you will nd the 3RW5 soft starter in the conguration software of the
controller under "Additional eld devices" (e.g. for STEP 7 in the HW Catalog).
2. Select the 3RW5 soft starter in the conguration software of the controller.
3. Insert the 3RW5 soft starter into the PROFINET IO system.
Conguring
6.2 Conguring the 3RW5 Soft Starter
SIRIUS 3RW5 PROFINET communication modules
Equipment Manual, 05/2021, A5E35631297002A/RS-AD/004 63
