Siemens PROFINET SIRIUS 3RW5 User Manual

Object
No.
Byte Bit Data format Parameters Value range
[encoding]
Incre‐
ment
3RW5 HMI HF
1)
50 / 52
[D
2)
]
55 / 55‑F
[D
3)
]
89 113 0 Bit2 Trace Mode
6)
[0 ... 2] - r
[0]
r
[0]
[0] Do not save automatical‐
ly
[1] Save automatically
[2] Save automatically and
delete older traces
90 114 0 Unsigned16 Maximum Number
Traces
6)
1 ... 255
[1 ... 255]
1 r
[1]
r
[1]
87 116 0 Bool Do Control After Log O󹪜 [0 ... 1] - r/w
[0]
r/w
[0]
[0] Stop motor and give back
control
[1] Continue with motor
control
- 117 ...
119
- - Reserved - - - -
1)
Supported by 3RW5 HMI High Feature
2)
Default encoding for 3RW5 HMI High Feature on the SIRIUS 3RW50 or 3RW52 soft starter
3)
Default encoding for 3RW5 HMI High Feature on the SIRIUS 3RW55 or 3RW55 Failsafe soft starter
4)
Not supported by SIRIUS 3RW50 and 3RW52 soft starter
5)
3RW5 HMI High Feature 󹪝rmware version V3.0 or higher
6)
3RW5 HMI High Feature 󹪝rmware version V3.1 or higher
A.4.7 I&M data
The 3RW5 PROFINET communication modules, the 3RW5 soft starters and the 3RW5 HMI High
Feature support the following I&M data:
I&M data 3RW5
Number Name Comment PN
1)
50 / 52 / 55 /
55‑F
2)
HMI
HF
3)
I&M0 Device identi󹪝cation This is stored in the device on initialization. x x x
I&M1 Equipment identi󹪝er These are entered in the engineering system. - x -
I&M2 Installation - x -
I&M3 Description - x -
1)
Supported by SIRIUS 3RW5 PROFINET communication module
2)
Supported by SIRIUS 3RW50, 3RW52, 3RW55 und 3RW55 Failsafe soft starters
3)
Supported by 3RW5 HMI High Feature
Appendix
A.4 Data sets
SIRIUS 3RW5 PROFINET communication modules
Equipment Manual, 05/2021, A5E35631297002A/RS-AD/004 201
