A.4.5.4 Data set 94: Measured values
Only read (r) access to the measured values is possible.
Byte Data format Meaning 3RW
50
1)
52
2)
55 /
55-F
3)
0 Unsigned8 Coordination x x x
2 Unsigned8 Slot number x x x
4 Unsigned16 Length of data structure x x x
6 Unsigned16 Start position x x x
1)
Supported by SIRIUS 3RW50 soft starter
2)
Supported by SIRIUS 3RW52 soft starter
3)
Supported by SIRIUS soft starter 3RW55 and 3RW55 Failsafe
Byte Data format Measured value Value range Incre‐
ment
3RW
50 /
52
1)
55 /
55-F
2)
12 Unsigned8 Phase current I L1 (%) 0 … 796.9 % 3.125 % r r
13 Unsigned8 Phase current I L2 (%) 0 … 796.9 % 3.125 % r r
14 Unsigned8 Phase current I L3 (%) 0 … 796.9 % 3.125 % r r
16 Unsigned16 Remaining motor cooling time 0 … 1 800 s 0.1 s r r
19 Unsigned8 Asymmetry 0 … 100 % 1 % - r
20 Unsigned16 Motor temperature rise 0 … 1000 % 1 % r r
28 Unsigned8 Output frequency 0 … 100 Hz 0.5 Hz - r
32 Unsigned8 Line frequency 0 … 100 Hz 0.5 Hz - r
34 Unsigned16 Line-to-line voltage U L1-L2 (rms) 0 … 1 500 V 0.1 V - r
36 Unsigned16 Line-to-line voltage U L2-L3 (rms) 0 … 1 500 V 0.1 V - r
38 Unsigned16 Line-to-line voltage U L3-L1 (rms) 0 … 1 500 V 0.1 V - r
40 Signed32 Phase current I L1 (rms) -20 000 … 20 000 A 0.01 A r r
44 Signed32 Phase current I L2 (rms) -20 000 … 20 000 A 0.01 A r r
48 Signed32 Phase current I L3 (rms) -20 000 … 20 000 A 0.01 A r r
55 Unsigned8 Switching element heating 0 … 250 % 1 % r r
56 Unsigned16 Remaining switching element cooling time 0 … 1 800 s 0.1 s r r
58 Unsigned16 Remaining time for motor overload protection 0 … 6 500 s 0.1 s - r
60 Signed32 Active power -2 147.483 …
2 147.483 kW
0.0001
kW
- r
66 Unsigned8 Power factor L1...3 0 … 1 0.01 - r
