A.4.3 Commands
A.4.3.1 Data set 93: Commands
Only write (w) access to the command is possible.
Byte Data format Meaning 3RW
50
1)
52
2)
55 /
55‑F
3)
0 Unsigned8 Coordination
[0x21] Write via acyclic bus channel – user program
x x x
2 Unsigned8 Slot number x x x
4 Unsigned8 Number of commands x x x
5 Unsigned8 Command 1 x x x
6 Unsigned8 Command 2 (optional) x x x
7 Unsigned8 Command 3 (optional) x x x
8 Unsigned8 Command 4 (optional) x x x
9 Unsigned8 Command 5 (optional) x x x
1)
Supported by SIRIUS 3RW50 soft starter
2)
Supported by SIRIUS 3RW52 soft starter
3)
Supported by SIRIUS soft starter 3RW55 and 3RW55 Failsafe
The coding of the commands is described in the following table:
Code Command 3RW5
50 /
52
1)
55
2)
55‑F
3)
0 No function x x x
1 Reset w w w
2 Enable Emergency start - w w
3 Disable Emergency start - w w
4 Automatic mode w w w
5 Manual operation w w w
6 Factory settings w w w
7 Reset maximum pointer w
4)
w w
9 Restart w w w
20 Delete logbook application - error w w w
22 Delete logbook application - warning - w w
24 Delete logbook application - events - w w
42 Enable Emergency run - w
5)
-
43 Disable Emergency run - w
5)
-
44 Activate simulation - w
6)
-
45 Deactivate simulation - w
6)
-
46 Activate test with small load w
4)
w w
47 Deactivate test with small load w
4)
w w
