Byte Data format Statistic data Value range Incre‐
ment
3RW
50 /
52
1)
55 /
55-F
2)
52 Unsigned32 Operating hours - motor current = 90 ... 119.9% x
Iemax
0 … 4 294 967 295 s 1 s r r
56 Unsigned32 Operating hours - motor current = 120 ... 1000% x
Iemax
0 … 4 294 967 295 s 1 s r r
62 Unsigned16 Number of switching element overload trips 0 … 65 535 1 r r
64 Unsigned16 Number of bypass overload trips 0 … 65 535 1 r r
72 Unsigned32 Number of electrical braking stops 0 … 4 294 967 295 1 - r
76 Unsigned32 Number of starts output 1 0 … 4 294 967 295 1 - r
80 Unsigned32 Number of starts output 2 0 … 4 294 967 295 1 - r
84 Unsigned32 Number of starts output 3 0 … 4 294 967 295 1 - r
88 Unsigned32 Number of starts output 4 0 … 4 294 967 295 1 - r
128 Float32 Active energy import (total) 0 …
4 294 967 295 Wh
1 Wh - r
136 Float32 Active energy export (total) 0 …
4 294 967 295 Wh
1 Wh - r
144 Unsigned16 Last real starting time 0 … 1 000 s 0.1 s - r
146 ...
199
- Reserved - - - -
1)
Supported by SIRIUS 3RW50 soft starter from 󹪝rmware version V1.0 and 3RW52 from 󹪝rmware version V2.0
2)
Supported by SIRIUS 3RW55 and 3RW55 Failsafe soft starters
A.4.5.6 Data set 96: Maximum pointer
Only read (r) access to the maximum pointer is possible.
Byte Data format Meaning 3RW
50
1)
52
2)
55 /
55-F
3)
0 Unsigned8 Coordination x x x
2 Unsigned8 Slot number x x x
4 Unsigned16 Length of data structure x x x
6 Unsigned16 Start position x x x
1)
Supported by SIRIUS 3RW50 soft starter
2)
Supported by SIRIUS 3RW52 soft starter
3)
Supported by SIRIUS soft starter 3RW55 and 3RW55 Failsafe
Byte Data format Maximum pointer Value range Incre‐
ment
3RW
50 /
52
1)
55 /
55-F
2)
12 Unsigned8 Minimum phase current I L1 (%) 0 … 796.9 % 3.125 % r r
13 Unsigned8 Phase current I L2 min (%) 0 … 796.9 % 3.125 % r r
14 Unsigned8 Phase current I L3 min (%) 0 … 796.9 % 3.125 % r r
