Siemens PROFINET SIRIUS 3RW5 - Data Set 131: Parameter Communication (Slot 1)

Byte Bit Data format Communication module diagnostics 3RW5
PN HF
1)
20 0 Bool OPC UA server active r
2), 3)
2 Bool Invalid security settings r
2), 3)
21 ... 27 - - Reserved -
1)
Supported by SIRIUS 3RW5 PROFINET High Feature communication module
2)
3RW5 PROFINET High Feature communication module from 󹪝rmware version V2.0
3)
Soft starter 3RW55 with 󹪝rmware version V2.1.1 or higher or soft starter 3RW55 Failsafe with 󹪝rmware version V1.1.0 or
higher
A.4.4.2 Data set 131: Parameter communication (slot 1)
Read (r) and write (w) access to the parameter communication is possible.
Byte Data format Meaning 3RW
50
1)
52
2)
55 /
55‑F
3)
0 Unsigned8 Coordination
[0x21] Write via acyclic bus channel – user program
x x x
2 Unsigned8 Slot number x x x
4 Unsigned16 Length of data structure x x x
6 Unsigned16 Start position x x x
1)
Supported by SIRIUS 3RW50 soft starter
2)
Supported by SIRIUS 3RW52 soft starter
3)
Supported by SIRIUS soft starter 3RW55 and 3RW55 Failsafe
Byte Bit Data format Parameter Range of values
[encoding]
3RW5 PN
Std
1)
[D
3)
]
HF
2)
[D
3)
]
10 1 Bool Group error [0 ... 1] r/w
[1]
r/w
[1]
[0] Disable
[1] Enable
2 Bool Group warning [0 ... 1] r/w
[1]
r/w
[1]
[0] Disable
[1] Enable
Appendix
A.4 Data sets
SIRIUS 3RW5 PROFINET communication modules
162 Equipment Manual, 05/2021, A5E35631297002A/RS-AD/004
