Code Command 3RW5
50 /
52
1)
55
2)
55‑F
3)
51 Normal operation w
4)
w w
52 Test mode w
4)
w w
1)
Supported by SIRIUS 3RW50 and 3RW52 soft starters
2)
Supported by SIRIUS 3RW55 soft starter
3)
Supported by SIRIUS 3RW55 Failsafe soft starter
4)
3RW50 soft starter from rmware version V1.0 or 3RW52 soft starter from rmware version V2.0
5)
3RW55 soft starter from rmware version V2.1
6)
3RW55 soft starter from rmware version V2.0
A.4.4 3RW5 communication module (slot 1)
A.4.4.1 Data set 92: Communication module diagnostics (slot 1)
Only read (r) access to the communication module diagnostics is possible. The data set 92 of the
3RW5 communication module (slot 1) is supported only by the 3RW5 PROFINET High Feature
communication module.
Byte Data format Meaning 3RW
50
1)
52
2)
55 /
55‑F
3)
0 Unsigned8 Coordination x x x
2 Unsigned8 Slot number x x x
4 Unsigned16 Length of data structure x x x
6 Unsigned16 Start position x x x
1)
Supported by SIRIUS 3RW50 soft starter
2)
Supported by SIRIUS 3RW52 soft starter
3)
Supported by SIRIUS soft starter 3RW55 and 3RW55 Failsafe
Byte Bit Data format Communication module diagnostics 3RW5
PN HF
1)
10 0 Bool Bus error r
4 Bool Operation without PN control r
12 0 Bool FW update rejected r
1 Bool FW update active r
2 Bool FW update successful r
3 Bool FW update faulty r
16 0 Bool Webserver active r
2), 3)
Appendix
A.4 Data sets
SIRIUS 3RW5 PROFINET communication modules
Equipment Manual, 05/2021, A5E35631297002A/RS-AD/004 161
