Siemens PROFINET SIRIUS 3RW5 - Page 198

Object
No.
Byte Bit Data format Parameters Value range
[encoding]
Incre‐
ment
3RW5 HMI HF
1)
50 / 52
[D
2)
]
55 / 55‑F
[D
3)
]
72 12 0 Unsigned16 Measured value 1 [501 ... 65 534] - r/w
[528]
r/w
[528]
[501] Remaining motor cool‐
ing time
[502] Motor temperature
rise
[503] Asymmetry
4)
[504] Phase current I L1 (%)
[505] Phase current I L2 (%)
[506] Phase current I L3 (%)
[508] Output frequency
4)
[509] Line frequency
4)
[510] Line voltage U L1-L2
(rms)
4)
[511] Line voltage U L2-L3
(rms)
4)
[512] Line voltage U L3-L1
(rms)
4)
[513] Phase current I L1
(rms)
[514] Phase current I L2
(rms)
[515] Phase current I L3
(rms)
[518] Switching element
heating
[519] Remaining switching
element cooling time
[520] Remaining time for
motor overload protection
4)
[521] Active power
4)
[523] Power factor L1...3
4)
[526] Remaining switching
frequency monit. time
4)
[528] Phase current average
(%)
[530] Phase current average
(rms)
[531] Phase current max
(rms)
4)
[65 534] No operation
14 0 Unsigned16 Measured value 2 (see Measured value 1) - r/w
[530]
r/w
[530]
16 0 Unsigned16 Measured value 3 (see Measured value 1) - r/w
[513]
r/w
[510]
18 0 Unsigned16 Measured value 4 (see Measured value 1) - r/w
[514]
r/w
[521]
20 0 Unsigned16 Measured value 5 (see Measured value 1) - r/w
[515]
r/w
[523]
Appendix
A.4 Data sets
SIRIUS 3RW5 PROFINET communication modules
198 Equipment Manual, 05/2021, A5E35631297002A/RS-AD/004
