Procedure for con󹪝guring
STEP 7 as of V4.02 COM PROFIBUS as of V5.0 or other con󹪝guration
software
1. Start the SIMATIC Manager.
2. Integrate the GSD 󹪝le into HW Con󹪝g (see re‐
quirements).
3. Con󹪝gure the ET 200iSP with HW Con󹪝g.
– Create a new project
– Drag modules from the hardware catalog to
the con󹪝guration table
4. Save the con󹪝guration or download this to the
station of ET 200iSP.
1. Start COM PROFIBUS or the con󹪝guration soft‐
ware.
2. Integrate the GSD 󹪝le into COM PROFIBUS or the
con󹪝guration software (see Requirements).
3. Con󹪝gure the ET 200iSP with COM PROFIBUS or
the con󹪝guration software.
4. Save the con󹪝guration and download the con‐
󹪝guration to the DP master.
Procedure for parameter assignment of electronic modules
1. Start the SIMATIC Manager.
2. Select the process device network view as the default view using the menu
command Options > Settings > View > Process network view.
3. Create a new project with the menu command File > New. In the "New" dialog box that
appears, enter the desired project name and con󹪝rm the entry with "OK".
4. Now select the networks symbol, choose Insert new object > PC and Insert new object in
the shortcut menu
– PROFINET IO: PROFINET IO system.
– PROFIBUS DP: PROFIBUS DP master system.
5. In the left-hand pane of the window, select the PC icon. An icon labeled DP Interface now
appears in the right-hand pane of the window. Select it and choose "Object properties" in the
shortcut menu.
In the dialog box, select "PROFIBUS DP networks" under networks and con󹪝rm with "OK".
6. Select the network to which you want to connect the ET 200iSP.
Action PROFINET PROFIBUS
In the shortcut
menu, select
Insert new object > PROFINET IO. Insert new object > Remote I/O.
In the following di‐
alog box, enter:
• Name:
Designation of the ET 200iSP sta‐
tion (e.g. ET 200iSP).
• Address:
PROFINET IO address that you have
set on the interface module.
• Subnet mask:
Parameters of the network on the
IO controller
• Name:
Designation of the ET 200iSP sta‐
tion (e.g. ET 200iSP).
• Address:
PROFIBUS address that you have set
on the interface module.
• Number of "Remote I/O" objects:
Number of ET 200iSP stations that
you parameterize.
Con󹪝rm with "OK".
The right part of the window displays the new ET 200iSP station.
Commissioning and Diagnostics
7.4 Project Engineering with GSD File and SIMATIC PDM
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 163
