In the dialog of the module status tab, you can display the following channel-speci󹪝c diagnostic
data for the selected transceiver:
Channel-speci󹪝c
diagnostics
Channel
error
type
(CET)
Exten‐
ded
channel
error
type
(ECET)
Meaning Remedy
SFP – Temperature
threshold violation
(High)
0x8007 0x8001 The internal temperature
exceeds the high alarm lim‐
it. The transceiver is too hot.
1. Check to ensure that the alarm limit is set to
the correct value.
2. Check whether the ambient temperature of
the IM is within the speci󹪝ed temperature
range.
3. Replace the SFP transceiver.
4. Contact Technical Support.
SFP – TXBias thresh‐
old violation (High)
0x8007 0x8002 The TX Bias voltage exceeds
the high alarm limit. The
transmit diode current is
too high.
1. Check to ensure that the alarm limit is set to
the correct value.
2. Replace the SFP transceiver.
3. Contact Technical Support.
SFP – TXBias thresh‐
old violation (Low)
0x8007 0x8003 The TX Bias voltage drops
below the low alarm limit.
The transmit diode current
is too low.
SFP – TXPower
threshold violation
(High)
0x8007 0x8004 The optical TX power ex‐
ceeds the high alarm limit.
The sent optical power is
too high.
SFP – TXPower
threshold violation
(Low)
0x8007 0x8005 The optical TX power drops
below the low alarm limit.
The sent optical power is
too low.
SFP – RXPower
threshold violation
(High)
0x8007 0x8006 The optical RX power ex‐
ceeds the high alarm limit.
The received optical power
is too high.
1. Check to ensure that the alarm limit is set to
the correct value.
2. Check the remote SFP transceiver (same
wavelength, optical transmit power).
3. Replace the SFP transceiver.
4. Contact Technical Support.
Commissioning and Diagnostics
7.7 Diagnostic interrupts of the transceiver
ET 200iSP
168 Operating Instructions, 11/2022, A5E00247483-AK
