Requirements
Software requirements:
• PCS7 V9.1 SP2
• Step 7 V5.7 SP1
• S7 F-systems V6.4 Update 1
• PDM V9.2.2
• Latest version of the HSPs of the interface module and electronic modules:
– IM 152-1PN: HSP 0289 V1.0 or higher
– 8 DI NAMUR: HSP 0045 V2.11 or higher
– 4 DO: HSP 2009 V2.4 or higher
– 2 DO Relay UC60V/2A: HSP 2031 V1.7 or higher
– 4 AI RTD: HSP 2032 V1.5 or higher
• Current version of the EDD – PN_IOSYSTEM_SIEMENS_ET200iSP
Additional requirements:
• SIMATIC CPU 410-5H is used for R1 redundancy.
• The power consumption of the ET 200iSP station has been recalculated. It was taken into
account that IM 152-1PN requires more power than IM 152-1DP. See section "Restricted
Number of Connectable Electronics Modules (Page 70)".
• The compatibility of the electronic modules with IM 152-1PN was considered. See section
"Compatible electronic modules (Page 282)".
WARNING
• Replacement of IM 152-1DP by IM 152-1PN is not allowed in process mode.
• In a redundant station, a mixed conguration (IM 152-1PN together with IM 152-1DP) is not
allowed.
• When using the IM 152-1PN interface module, observe the Class 1 limits according to IEC
60825-1. Only use approved media converters and ber-optic cables.
Replacement of the interface module
1. Switch o the supply voltage of the ET 200iSP station.
2. Pull out the PROFIBUS cable (PROFIBUS RS 485-IS) from the termination module.
3. Remove the IM 152-1DP interface module (or both interface modules in case of R1
redundancy) from the termination module. See section "Inserting and labeling the interface
module and electronic modules (Page 143)".
4. If the ET 200iSP RS 485-IS coupler is not used for other stations, remove the ET 200iSP RS 485-
IS coupler.
Commissioning and Diagnostics
7.14 Changing PROFIBUS station to PROFINET station
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 221
