Pulse-shaped interference Test voltage Corresponds to degree
of severity
High-energy single pulse (surge) in accordance with IEC 61000-4-5
As of product version 3 of power supply PS (6ES7138-7EA01-0AA0), the over‐
voltage suppressor for the DC 24V supply at the power supply PS is no longer
mandatory.
Surge arresters are required for all signal modules (for appropriate types, see
Appendix Lightning and overvoltage protection (Page 442))
3
• asymmetric connection
+/- 2 kV (supply line)
+/- 2 kV (signal line / data cable)
• symmetrical coupling
+/- 1 kV (supply line)
+/- 1 kV (signal line / data cable)
NAMUR recommendation NE21
Electrostatic discharge according to NA‐
MUR recommendation NE21
Air discharge: +/-8 kV
Contact-mode discharge: +/- 6 kV
3
Burst pulses
according to NAMUR recommendation
NE21
+/- 2 kV (supply line)
+/- 1 kV (signal line)
3
High-energy single pulse (surge) according to Namur recommendation NE21 3
• asymmetric connection
+/- 1 kV (supply line)
+/- 1 KV (signal line / data cable)
• symmetrical coupling
+/- 0.5 kV (supply line)
Modules that can be wired according to NAMUR recommendation NE21
Type Article number
PS DC24V 6ES7138-7EA01-0AA0
PS AC120/230V 6ES7138-7EC00-0AB0
IM 152-1PN 6ES7152-1BA00-0AB0
IM 152-1DP 6ES7152-1AA00-0AB0
4 DO DC23.1V/20mA 6ES7132-7RD01-0AB0
4 DO DC25.5V/22mA 6ES7132-7GD30-0AB0
4 DO DC17.4V/40mA 6ES7132-7GD21-0AB0
4 AI I 2WIRE HART 6ES7134-7TD00-0AB0
4 AI I 4WIRE HART 6ES7134-7TD50-0AB0
4 AI TC 6ES7134-7SD00-0AB0
4 AO I HART 6ES7135-7TD00-0AB0
Sinusoidal interference variables
The following table shows the electromagnetic compatibility of the ET 200iSP distributed I/O
device in relation to sinusoidal interference variables.
• HF irradiation
General technical specications
9.3 Electromagnetic compatibility, transport and storage conditions
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 243
