Siemens SIMATIC ET 200iSP

Article number 6ES7132-7RD01-0AB0
• Wire-break
Yes; R > 10 kohms, I < 100 µA
• Short-circuit
Yes; R< 800 ohms (one output), R< 40 ohms (out‐
puts connected in parallel)
Diagnostics indication LED
• Group error SF (red)
Yes
• Status indicator digital output (green)
Yes
Potential separation
Potential separation digital outputs
• between the channels
No
• between the channels and backplane bus
Yes
• Between the channels and load voltage L+
Yes
Standards, approvals, certi󹪝cates
Highest safety class achievable in safety mode
• SIL acc. to IEC 61508
No
Dimensions
Width 30 mm
Height 129 mm
Depth 136.5 mm
Weights
Weight, approx. 255 g
Digital electronic modules
13.2 Digital electronics module 4 DO
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 309
