4 DO DC17.4V/27mA shut down "H"
Article number 6ES7132-7RD11-0AB0
General information
Product type designation 4DQ 17.4 V DC/27 mA
Input current
Current consumption, typ. 260 mA
from load voltage L+ (without load), max. 300 mA
from backplane bus 3.3 V DC, max. 10 mA
Power loss
Power loss, typ. 2.1 W
Address area
Address space per module
• Address space per module, max.
2 byte
Digital outputs
Type of digital output Transistor
Number of digital outputs 4; additionally 1 intrinsically-safe input for H shut‐
down
Short-circuit protection Yes
No-load voltage Uao (DC) 17.4 V
Internal resistor Ri 150 Ω
Trend key points E
• Voltage Ue (DC)
13.3 V
• Current Ie
27 mA
Output current
• for signal "1" rated value
0.027 A
Output delay with resistive load
• "0" to "1", max.
2 ms
• "1" to "0", max.
1.5 ms
Parallel switching of two outputs
• for uprating
Yes
Switching frequency
• with resistive load, max.
100 Hz
• with inductive load, max.
2 Hz
Cable length
• shielded, max.
500 m
• unshielded, max.
500 m
Interrupts/diagnostics/status information
Diagnostics function Yes
Alarms
• Diagnostic alarm
Yes; Parameterizable
Diagnoses
• Diagnostic information readable
Yes
• Wire-break
Yes
Digital electronic modules
13.2 Digital electronics module 4 DO
ET 200iSP
310 Operating Instructions, 11/2022, A5E00247483-AK
