Technical speci󹪝cations
Article number 6ES7132-7HB00-0AB0
General information
Product type designation 2DQ relay 60 V UC/2 A
Input current
Current consumption, typ. 100 mA
from load voltage L+ (without load), max. 120 mA
Power loss
Power loss, typ. 1.1 W
Digital outputs
Type of digital output Relays
Number of digital outputs 2
Short-circuit protection No
Output current
• for signal "1" rated value
2 A
Output delay with resistive load
• "0" to "1", max.
8 ms
• "1" to "0", max.
3 ms
Parallel switching of two outputs
• for uprating
No
• for redundant control of a load
No
Switching frequency
• with resistive load, max.
0.5 Hz; See data in manual
• with inductive load, max.
0.2 Hz; See data in manual
Relay outputs
Switching capacity of contacts
– with resistive load, up to 60 °C, max.
2 A; See data in manual
– Thermal continuous current, max.
2 A; See data in manual
Cable length
• shielded, max.
500 m
• unshielded, max.
500 m
Interrupts/diagnostics/status information
Substitute values connectable Yes
Alarms
• Diagnostic alarm
Yes
• Hardware interrupt
No
Diagnoses
• Diagnostic information readable
Yes
• Wire-break
No; Cannot be determined in contact power circuit
• Short-circuit
No; Cannot be determined in contact power circuit
Diagnostics indication LED
• Group error SF (red)
Yes
• Status indicator digital output (green)
Yes; Per channel
Digital electronic modules
13.3 Digital electronic module 2 DO Relay UC60V/2A
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 331
