Siemens SIMATIC ET 200iSP User Manual

Article number 6ES7132-7HB00-0AB0
Ex(i) characteristics
maximum values for connecting terminals for
gas group IIC
• Uo (no-load voltage), max.
60 V
• Um (voltage at non-intrinsically safe connect‐
ing terminals), max.
250 V
Potential separation
Potential separation digital outputs
• between the channels
Yes
• between the channels and backplane bus
Yes
• Between the channels and load voltage L+
Yes; Channels and power bus
Standards, approvals, certi󹪝cates
CE mark Yes
Highest safety class achievable in safety mode
• SIL acc. to IEC 61508
No
Dimensions
Width 30 mm
Height 129 mm
Depth 136.5 mm
Weights
Weight, approx. 255 g
Technical speci󹪝cations
Module-speci󹪝c data
Voltages, currents, electrical potentials
Permissible potential di󹪜erence
• between di󹪜erent circuits
DC 60 V
Current consumption from load voltage (power bus) max. 105 mA
Status, interrupts, diagnostics
Status display
• Outputs
Green LED for each channel
Diagnostic functions
• Group error display
Red "SF" LED
Safety data
U
m
= DC 250 V / AC 250 V
For additional information, see certi󹪝cate
IECEx KEM 07.0059
https://www.iecex.com (https://www.iecex.com)
KEMA 07 ATEX0180 INMETRO UL-BR 12.0078
https://support.industry.siemens.com (https://support.industry.siemens.com)
Output delay (resistive load)
Digital electronic modules
13.3 Digital electronic module 2 DO Relay UC60V/2A
ET 200iSP
332 Operating Instructions, 11/2022, A5E00247483-AK
