Parameters Range of values Default Applicability
Sensor type
• Channel disabled
• NAMUR sensor
• Single contact unconnected
• Single contact connected
with 10 kΩ
• NAMUR change-over con‐
tact
• Change-over contact, un‐
connected
• Change-over contact con‐
nected with 10 kΩ
NAMUR sensor Channel
Pulse stretching
• None
• 0.5 s
• 1 s
• 2 s
None Channel
Group diagnostics
• Enabled
• Disabled
Enabled Channel
Diagnostics: wire break
• Enabled
• Disabled
Enabled Channel
Diagnostics: short-circuit
• Enabled
• Disabled
Enabled Channel
Diagnostics: 󹪞utter error
• Enabled
• Disabled
Disabled Channel
External error
(changeover contact error or
encoder supply faulty)
• Enabled
• Disabled
Disabled Channel
Flutter monitoring: Monitor‐
ing window
2
• 0.5 s
• 1 s to 100 s (adjustable in 1
s steps)
2 s Channel
Flutter monitoring: Number
of signal changes
2
2 to 31 5 Channel
1
Con󹪝gurable only in HW Con󹪝g and when you operate the ET 200iSP as an S7 DP device. Time stamping is only allowed for
IM 152-1DP.
2
The parameter can only be set if the chatter error diagnostics has been enabled.
Digital electronic modules
13.5 Parameters of the digital electronic modules
ET 200iSP
336 Operating Instructions, 11/2022, A5E00247483-AK
