Parameters 8 DI NAMUR, con󹪝guration "2 Count/ 6 DI NAMUR" and "2 Count/ 6 Control"
In addition to the con󹪝guration "8 DI NAMUR", the following parameters can be set for counting:
Table 13-15 Parameters for "2 Count/ 6 DI NAMUR" and "2 Count/ 6 Control"
Parameters Range of values Default Applicability
Encoder type counter inputs
• Channel disabled
• NAMUR sensor
• Single contact unconnected
NAMUR sensor Channel
Counter 1 mode
• Standard counting function
• Periodic counting function
• Cascaded counting function
Standard counting function Channel 0
Counter 2 mode
• Standard counting function
• Periodic counting function
Standard counting function Channel 1
Parameters 8 DI NAMUR, con󹪝guration "2 Count/ 6 Control"
In addition to the con󹪝guration "8 DI NAMUR", the following parameters can be set for counting:
Table 13-16 Parameters for "2 Count/ 6 Control"
Parameters Range of values Default Applicability
Control channel
• Channel disabled
• NAMUR sensor
• Single contact unconnected
NAMUR sensor Channel
Parameters 8 DI NAMUR, con󹪝guration "2 Trace/ 6 DI NAMUR"
In addition to the con󹪝guration "8 DI NAMUR", the following parameters can be set when
measuring frequencies:
Table 13-17 Parameters for "2 Trace/ 6 DI NAMUR"
Parameters Range of values Default Applicability
Encoder type frequency in‐
puts
• Channel disabled
• NAMUR sensor
• Single contact unconnected
NAMUR sensor Channel
Measuring window (TOR)
• 50 ms
• 200 ms
• 1 s
1 s Channel
Digital electronic modules
13.5 Parameters of the digital electronic modules
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 337
